PECULIARITY
- Maximum energy efficiency with flame modulation system and functioning at condensation
conditions.
- Maximum performance rate about 102%.
- AISI 430 stainless steel combustion chamber.
- AISI 304 stainless steel, corrosion-resistant heat exchanger.
- Screw-threaded connector for condensate discharge.
- Suitable for coupling with all kinds of modulating burners.
- Centrifugal fans with variable-diameter transmission pulley and electric engine equipped with
belt tightener.
- Standard version 250 PA, “S version” with high static pressure 450 PA.
- Standard version running until -20°C, down until -45°C with low-temperature kit.
ENERGY
condensing WARM AIR HEATERS
WITH MODULATING BURNER
EFFICIENCY ~102%
SERIES
