38
39
Thermal Performance GASTEC certified
TECHNICAL SPECIFICATIONS
SERIES
ENERGY-O
AERAULIC SECTION
Models Unit
ENERGY-O 60 ENERGY-O 105 ENERGY-O 160 ENERGY-O 220 ENERGY-O 320 ENERGY-O 460 ENERGY-O 640 ENERGY-O 970
Nominal air flow Nm
3
/h 4.600 8.000 11.000 15.000 21.500 31.000 43.000 71.000
USEFUL static press. std motor Pa 220 220 220 220 220 220 220 220
Standard motor power
kW 1,1 2,2 3,0 4,0 5,5 9,2 15,0 2 x 11,0
USEFUL static press. bigger motor
Pa 450 450 450 450 450 450 450 450
Bigger motor power
kW 1,5 3,0 4,0 2 x 3,0 7,5 2 x 5,5 18,5 3 x 9,2
HEATING SECTION
gas HEaT EXCHaNgER - MaX OUTPUT fUNCTiONiNg
Models Unit
ENERGY-O 60 ENERGY-O 105 ENERGY-O 160 ENERGY-O 220 ENERGY-O 320 ENERGY-O 460 ENERGY-O 640 ENERGY-O 970
Max. USEFUL heating capacity
kW 60,0 103,0 160,0 220,0 320,0 460,0 640,0 970,0
kcal/h 51.600 88.580 137.600 189.200 275.200 395.600 550.400 834.000
Max. temperature deviation °K 38,0 39,0 43,5 43,5 44,5 44,0 44,0 41,0
gas HEaT EXCHaNgER - MiN OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models Unit
ENERGY-O 60 ENERGY-O 105 ENERGY-O 160 ENERGY-O 220 ENERGY-O 320 ENERGY-O 460 ENERGY-O 640 ENERGY-O 970
Max. efficiency % 101,2 101,3 101,4 101,6 102,0 102,2 102,2 101,0
Min. USEFUL heating capacity
kW 30,0 52,5 80,0 110,0 160,0 230,0 320,0 485,0
kcal/h 25.800 45.150 68.800 94.600 137.600 196.800 275.200 417.100
Min. temperature deviation °K 19,0 19,5 21,7 21,7 22,2 22,0 22,0 20,5
ELECTRICAL SPECIFICATION
Models Unit
ENERGY-O 60 ENERGY-O 105 ENERGY-O 160 ENERGY-O 220 ENERGY-O 320 ENERGY-O 460 ENERGY-O 640 ENERGY-O 970
Electrical supply
V - 50Hz
400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~
