5454
5555
Models Unit FRESH 15 FRESH 20 FRESH 25 FRESH 30 FRESH 35 FRESH 40 FRESH 45 FRESH 50
Cooling capacity output
kW 6,5 8,9 11,5 15,1 18,9 22,7 28,7 37,0
frig/h 5.590 7.654 9.890 12.986 16.254 19.522 24.682 31.820
Absorbed compr. power kW 2,00 2,56 3,24 3,92 5,01 5,67 7,02 9,16
E.E.R. kW/kW 3,25 3,48 3,55 3,85 3,77 4,00 4,09 4,04
Nominal water flow m
3
/h 1,00 1,30 1,70 2,40 3,10 3,60 4,50 5,90
Gas R 410 A quantity Kg 1,2 1,8 2,8 3,0 5,0 5,8 8,4 9,8
Axial fan
n° 1 1 2 2 2 2 4 4
Electrical supply
V - 50Hz 230 ~ 230 ~ 230 ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~ 400 3N ~
OPTIONAL
Models Unit FRESH 15 FRESH 20 FRESH 25 FRESH 30 FRESH 35 FRESH 40 FRESH 45 FRESH 50
Storage tank liters 16 16 36 36 57 57 70 70
Cooling performance following EUROVENT conditions
TECHNICAL SPECIFICATIONS SERIES
FRESH
