Chapter 6. Browser / Telnet Operation
105
1. Network
+++++++++++++++++++++++++++++++++++++++++++++++
KE6940A Receiver
-- -- -- -- -- -- -- -- --
Network Settings
+++++++++++++++++++++++++++++++++++++++++++++++
1. IP Installer [Enabled]
2. DHCP [Disabled]
3. IP Address [172.17.17.34]
4. Subnet Mask [255.255.255.0]
5. Default Gateway [172.17.17.254]
Q. Exit
Select one:
2. Properties
+++++++++++++++++++++++++++++++++++++++++++++++
KE6940A Receiver
-- -- -- -- -- -- -- -- --
Device Properties
+++++++++++++++++++++++++++++++++++++++++++++++
1. Mode [Matrix]
2. Transmitter Video IP Address [172.17.17.35]
3. Transmitter Audio IP Address [172.17.17.35]
4. Transmitter USB IP Address [172.17.17.35]
5. Transmitter RS232 IP Address [172.17.17.35]
6. UART Configuration
7. Video [Enabled]
8. Audio [Enabled]
9. USB [Enabled]
10. RS232 [Enabled]
11. KVM over IP Matrix Manager IP [172.17.17.33]
12. KVM over IP Matrix Manager Port [9110]
13. Beeper [Enabled]
14. USB Mode [VM]
15. USB Secure Transmit [Disabled]
Q. Exit
Select one:
