RCM KVM over IP Transmitter User Manual

106

3. System

+++++++++++++++++++++++++++++++++++++++++++++++

KE6940A Receiver

-- -- -- -- -- -- -- -- --

System Setting

+++++++++++++++++++++++++++++++++++++++++++++++

1. Device Name [KE6940AR]

2. Device Description [Receiver1]

Device IP Address: 172.17.17.34

Device MAC Address: 00:10:74:A8:01:23

Device FW Version: V1.1.109

Device Serial Number:

3. Password [Enabled]

4. Change Password

5. System Reboot/Reset to Factory Default

Q. Exit

Select one:

Note: The Reset to Factory Default function resets everything but the login

information to the factory default settings. To reset the login

information, refer to Reset All Information on page 266.
