Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 3-27
Image Quality
3 Inspect the Registration Roller and
the Registration Pinch Roller for wear
or damage.
Is either part worn or damaged?
Replace the
Registration
Roller
(page 4-27),
then go to
Step 6.
Go to Step 4.
4 Does the image print correctly? Complete. Go to Step 5.
5 Replace the Feed Roller (page 4-17).
Does the image print correctly?
Complete. Go to Step 6.
6 Replace the Separator Pad
(page 4-74).
Does the image print correctly?
Complete. Go to Step 7.
7 Replace the MCU Board (page 4-43).
Does the image print correctly?
Complete. Contact field
support for
assistance.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
