Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 5-31
Parts Lists
Parts List 2.2 Feeder (2/3)
Item Name Part Number
1 Feed Roll Assembly (with 1-7) 059K71563
2Cam MSI L
3 Roll Core
4 Roll Assy Feed
5Holder Feed
6Shaft Feed
7Cam MSI R
8 Bottom Plate (with 9,10) 815K07610
9Pad MSI
10 Plate BTM
11 Holder BTM L
12 Holder BTM R
13 Follower L
14 Follower R
15 Separator Pad Assembly 848K49666
16 Arm MSI R
17 Spring NF
18 Arm MSI L
19 Feed Gear 807E36162
20 Spring Feed
