Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 5-33
Parts Lists
Parts List 2.3 Feeder (3/3)
Item Name Part Number
1Chute Upper
2 Roll Assy Pinch REGI (with 3-5)
3 Roll Pinch REGI10
4 Roll Pinch REGI30
5 Shaft Pinch REGI
6 Registration Roller 059E07550
7Chute Low
8Spring Actuator REGI
9 Registration Sensor Actuator 120E33031
10 Registration Sensor 930W00123
11 Spring Earth REGI
12 Bearing REGI Earth
13 Bearing REGI Metal Earth
14 Spring Turn
15 Bearing REGI Metal
16 Bearing REGI
17 Spring REGI Clutch
18 FLANGE REGI Clutch
19 GEAR REGI Clutch
20 Cover Solenoid
21 Feed Solenoid 121E22993
22 Harness Assy REG SNS
