107
8
SCAN OPERATION
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
18
19
D Scan start/stop via the microphone
SCAN
2
z Push [VFO/LOCK] to select the VFO mode for
full/band/programmed scan; push [MR/CALL] to
select the memory mode for memory scan.
• Push [FUNC] + [MONI 1(BANK)] then push [Y]/[Z]
to select a bank for memory bank scan. Push
[CLR A(MW)].
x Push [SCAN 2(T-SCAN)].
c Push [Y]/[Z] to select the desired scanning
type.
• For full/band/programmed scan
“ALL” for full scan; “BAND” for band scan, “P-LINK x
(or program scan link name if programmed)” for pro-
grammed link scan (x= 0 to 9), “PROGxx (or scan
name if programmed)” for programmed scan (xx= 0
to 24; only programmed scan edge numbers are dis-
played), “DUP” (appears only when duplex operation
is set) for duplex scan
, “TONE” (appears only when the
subaudible tone, tone squelch or DTCS squelch is set)
for tone scan.
• For memory scan
“ALL” for all memory scan; “BAND” for band memory
scan, “MODE” for mode scan, “DUP” (appears only
when duplex operation is set) for duplex scan
, “TONE”
(appears only when the subaudible tone, tone squelch or
DTCS squelch is set) for tone scan.
SCAN
2
• For memory bank scan
“ALL” for all bank scan; “B-LINK” for bank link scan
or “BANK-
x” for bank scan (x= A to Z; programmed
bank groups are only displayed.), “DUP” (appears only
when duplex operation is set) for duplex scan
, “TONE”
(appears only when the subaudible tone, tone squelch or
DTCS squelch is set) for tone scan.
v Push [SCAN 2(T-SCAN)] again to start the scan.
b To stop the scan push [
SCAN 2(T-SCAN)] or
[
CLR A(MW)].
• Push [Y]/[Z] also stops the scan.
YZ
z Push [VFO/LOCK] to select the VFO mode for full
scan; push [MR/CALL] to select the memory
mode for memory scan.
• Push [FUNC] + [MONI 1(BANK)] then push [Y]/[Z]
to select a bank for memory bank scan. Push
[CLR A(MW)].
x Push and hold [Y]/[Z] to start the scan.
c Push [Y]/[Z] to stop the scan.
