118
10
MENU SCREEN OPERATION
MENU screen indication and arrangement
MENU screen shows one of the following indication.
• TS mode
• SCAN mode
• SET mode
Setting (see p. 15)
Independent items
(see p. 123)
- FUNC mode
- DISP mode
- SOUNDS mode
• DUP.T mode
Independent items
(see p. 121)
• CALL-S mode
Independent items
(see p. 31)
• RX CAL mode
Independent items
(see p. 44)
• MESSAG mode
Independent items
(see p. 64)
• RPT-L mode
Independent items
(see p. 34)
• GPS mode
Independent items
(see p. 138)
Independent items
(see p. 134)
• DV SET mode
Independent items
(see p. 127)
Independent items
(see p. 130)
Independent items
(see p. 132)
