71
5
DV MODE OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D Transmission condition setting
q Enter “DATATX” in the DV SET mode.
MENU ¶ DV SET ¶ DATATX
(Push [MENU ]), (rotate [DIAL], then push [ ](MONI).)
w Rotate [DIAL] to select “PTT” or “AUTO.”
PTT : The input data from [DATA] are transmitted when
pushing [PTT]. (default)
AUTO : The input data from [DATA] are transmitted auto-
matically when the data are input.
e Push [ ](MONI) to return to the DV SET mode, and push
[MENU
] to return to frequency indication.
