Icom ID-880H [128/196] D setting pause timer via the microphone
![Icom ID-880H [128/196] D setting pause timer via the microphone](/views2/1074127/page128/bg80.png)
110
8
SCAN OPERATION
D Setting Pause timer via the microphone
z Push [BAND] to select the desired band.
x
Enter “PAUSE” in the SCAN set mode.
MENU ¶ SCAN ¶ PAUSE
(p. 123)
(Push [SET B(D-OFF)] to enter the MENU screen),
(Push [Y] or [Z], then push [SET B(D-OFF)].)
c Push [Y]/[Z] to select the scan resume condi-
tion, then push [
SET B(D-OFF)].
• See step w at previous page for scan pause timer
details.
v Push [CLR A(MW)] to exit set mode.
D Setting Resume timer via the microphone
z Push [BAND] to select the desired band.
x
Enter “RESUME” in the SCAN set mode.
MENU ¶ SCAN ¶ RESUME
(p. 123)
(Push [SET B(D-OFF)] to enter the MENU screen),
(Push [Y] or [Z], then push [SET B(D-OFF)].)
c Push [Y]/[Z] to select the scan resume condi-
tion, then push [
SET B(D-OFF)].
• See step w at previous page for scan resume timer
details.
v Push [CLR A(MW)] to exit set mode.
SET
B
Skip channel/frequency setting (continued)
SET
B
