OPTIONS
16
CS-80/880 CLONING SOFTWARE (free download)
Use this software to program settings such as memory chan-
nels and set mode contents quickly and easily via your PC’s
RS-232C terminal (using OPC-1529R or OPC-478), or USB
port (OPC-478UC). Either OPC-1529R, OPC-478 or OPC-
478UC is required.
This software can be downloaded from the Icom home page
via the Internet. Access the following URL to download the
software and the manual.
http://www.icom.co.jp/world/support/index.html
HM-103/154
HAND MICROPHONE
HM-133 REMOTE-CONTROL MICROPHONE
Remote control microphone with key backlight. Same as that
supplied with the transceiver.
OPC-347/1132
DC POWER CABLES
OPC-347 : 7.0 m; 27 ft
†
OPC-1132 : 3.0 m; 11.2 ft
†
Same as that supplied with the transceiver.
OPC-440/647
MIC EXTENSION CABLE
OPC-440: 5.0 m; 16.4 ft
†
OPC-647: 2.5 m; 8.2 ft
†
OPC-441 SPEAKER EXTENSION CABLE
5.0 m; 16.4 ft
†
OPC-474 CLONING CABLE
Used for data cloning between transceivers.
OPC-478/OPC-478UC
CLONING CABLE
Used for data cloning between transceiver and PC with CS-
80/880 (free download software).
OPC-478 : RS-232C type
OPC-478UC : USB type
OPC-589
MIC ADAPTOR CABLE
Allows you to connect a regular 8-pin microphone.
OPC-1529R
DATA COMMUNICATION CABLE (RS-232C type)
Allows low-speed data communication in the DV mode and
data cloning operation with CS-80/880 (free download soft-
ware).
SP-10
EXTERNAL SPEAKERS
For all-round mobile operation. Cable length: 1.5 m; 4.9 ft
†
MB-120 MOUNTING BASE
Mounts the remote controller on to variety of place in vehicle. Remote
controller bracket is required for mounting.
†
Approx.
