114
9
PRIORITY WATCH
D Memory/call channel and memory scan
watch via the microphone
PRIO
3
z Select the VFO mode; then, set the desired fre-
quency.
x Set the watched channel(s).
For memory channel watch:
Push [MR/CALL] then [Y] or [Z] to select the de-
sired memory channel.
For memory scan watch:
± Select the memory mode, or desired bank
group.
± Push [
SCAN 2(T-SCAN)] to enter the scan type
selection.
± Push [Y] or [Z] to select the desired scan
type, then push [
SCAN 2(T-SCAN)] to start the
memory scan.
For call channel watch:
Push [MR/CALL] for 1 sec. then push [Y] or [Z]
to select the call channel.
c Push [
PRIO 3(PTT-M)] to start the watch.
• The transceiver checks the memory or call channel
every 5 sec.
• The watch resumes according to the selected scan
resume condition. (p. 109)
• To resume the watch manually when paused, push
[PRIO 3(PTT-M)].
v To stop the watch, push [CLR A(MW)].
D VFO scan watch via the microphone
PRIO
3
z Select the VFO mode; then, set the desired fre-
quency.
x Set the watched channel(s).
For memory channel watch:
Push [MR/CALL] then [Y] or [Z] to select the de-
sired memory channel.
For memory scan watch:
± Select the memory mode, or desired bank group.
± Push [SCAN 2(T-SCAN)] to enter the scan type
selection.
± Push [Y] or [Z] to select the desired scan
type, then push [
SCAN 2(T-SCAN)] to start the
memory scan.
For call channel watch:
Push [MR/CALL] for 1 sec. then push [Y] or [Z]
to select the call channel.
c Push [
PRIO 3(PTT-M)] to start the watch.
• The transceiver checks the memory or call channel
every 5 sec.
• The watch resumes according to the selected scan
resume condition. (p. 109)
• To resume the watch manually when paused, push
[PRIO 3(PTT-M)].
v
Push [SCAN 2(T-SCAN)] to enter scan type selection.
b
Push [Y] or [Z] to select the desired scan type
from “ALL,” “BAND” “P-LINK x
(x= 0–9)” and
“PROGxx
(xx= 0–24),” “DUP.”
Continues to the next page
