104
Appliances equipped with heat exchanger
designed to produce extra hot air to be
employed for roasting processes. (600°C)
Appliances equipped with heat exchanger
designed to produce overheated air to be employed
for drying processes. (350°C)
Heat exchangers to be employed in the framework of
technological processes where overheated air with high
static pressure is required. (1,600 Pa)
Appliances equipped with heat exchanger
suitable to treat large air volumes at very low temperature;
designed to heat up mines. (140,000 Nm
3
/h, -55°C)
