Top-efficiency appliances designed
for air heating and cooling;
to be employed for air-conditioning
of large premises in the car industry.
Heat exchangers for the production of overheated air;
designed for bakery and industrial ovens.
Appliances equipped with heat exchanger designed
to produce overheated air with high static pressure;
to be employed in the framework of
shipyard technological processes
(120,000 Nm
3
/h, 200°C, 1,500 Pa).
Appliances equipped with heat exchanger designed
to work at modulating functioning mode
and with downwards air outlet;
to be employed in the greenhouse sector.
105
