Yamaha WR250F 2003 [186/304] Engine removal

4 - 82

ENG

ENGINE REMOVAL

EC4M0000

ENGINE REMOVAL

Extent of removal Order Part name Q’ty Remarks

ENGINE REMOVAL

Preparation for removal Hold the machine by placing the

suitable stand under the frame.

WARNING

Support the machine securely so there is no

danger of it falling over.

Seat and fuel tank Refer to “SEAT, FUEL TANK AND SIDE

COVERS” section.

Carburetor Refer to “CARBURETOR” section.

Exhaust pipe and silencer Refer to “EXHAUST PIPE AND

SILENCER” section.

Clutch cable Disconnect at engine side.

Radiator Refer to “RADIATOR” section.

Shift pedal Refer to “KICK SHAFT AND SHIFT

SHAFT” section.

Cylinder head breather hose and

oil tank breather hose

Refer to “CAMSHAFTS” section.

Drain the engine oil Refer to “ENGINE OIL REPLACEMENT”

section in the CHAPTER 3.
