SPEC
2 - 8
MAINTENANCE SPECIFICATIONS
Clutch:
Friction plate thickness 2.9 ~ 3.1 mm
(0.114 ~ 0.122 in)
2.7 mm
(0.106 in)
Quantity 9 ----
Clutch plate thickness 1.1 ~ 1.3 mm (0.043 ~ 0.051 in) ----
Quantity 8 ----
Warp limit ---- 0.1 mm
(0.004 in)
Clutch spring free length 40.4 mm (1.59 in) 39.4 mm
(1.55 in)
Quantity 5 ----
Clutch housing thrust clearance 0.10 ~ 0.35 mm
(0.0039 ~ 0.0138 in)
----
Clutch housing radial clearance 0.010 ~ 0.044 mm
(0.0004 ~ 0.0017 in)
----
Clutch release method Inner push, cam push ----
Shifter:
Shifter type Cam drum and guide bar ----
Guide bar bending limit ---- 0.05 mm
(0.002 in)
Kickstarter:
Type Kick and ratchet type ----
Carburetor: USA, CDN, ZA,
AUS, NZ
EUROPE
Type/manufacturer FCR-MX37/
KEIHIN
← ----
I. D. mark 5UL1 00 5UL2 10 ----
Main jet (M.J) #178 ← ----
Main air jet (M.A.J) ø2.0 ← ----
Jet needle (J.N) OBELP-4 OBEKP-4 ----
Cutaway (C.A) 1.5 ← ----
Pilot jet (P.J) #40 ← ----
Pilot air jet (P.A.J) #100 ← ----
Pilot outlet (P.O) ø0.9 ← ----
Pilot screw (example) (P.S) 1-5/8 ← ----
Bypass (B.P) ø1.0 ← ----
Valve seat size (V.S) ø3.8 ← ----
Starter jet (G.S) #72 ← ----
Leak jet (Acc.P) #100 ← ----
Float height (F.H) 8 mm (0.31 in) ← ----
Engine idle speed 1,900 ~
2,100 r/min
← ----
Intake vacuum 26.7 ~ 32.0 kPa
(200 ~ 240 mmHg,
7.87 ~ 9.45 inHg)
← ----
Hot starter lever free play 3 ~ 6 mm
(0.12 ~ 0.24 in)
← ----
Item Standard Limit
