Yamaha WR250F 2003 [48/304] Maintenance specifications
![Yamaha WR250F 2003 [48/304] Maintenance specifications](/views2/1012986/page48/bg30.png)
SPEC
2 - 12
MAINTENANCE SPECIFICATIONS
CHASSIS
Item Standard Limit
Steering system:
Steering bearing type Taper roller bearing ----
Front suspension: USA, CDN
AUS, NZ, ZA
EUROPE
Front fork travel 300 mm (11.8 in) ← ----
Fork spring free length 460 mm (18.1 in) ← 455 mm (17.9 in)
Spring rate, STD K = 4.22 N/mm
(0.43 kg/mm,
24.1 lb/in)
K = Approx.
4.22 N/mm
(0.43 kg/mm,
24.1 lb/in)
----
Optional spring/spacer Yes ← ----
Oil capacity 563 cm
3
(19.8 Imp oz,
19.0 US oz)
573 cm
3
(20.2 Imp oz,
19.4 US oz)
----
Oil level 140 mm (5.51 in) 130 mm (5.12 in) ----
<Min.~Max.>
(From top of outer tube with inner
tube and damper rod fully com-
pressed without spring.)
80 ~ 150 mm
(3.15 ~ 5.91 in)
← ----
Oil grade Suspension oil
“01”
← ----
Inner tube outer diameter 46 mm (1.81 in) ← ----
Front fork top end 5 mm (0.20 in) ← ----
Rear suspension: USA, CDN,
AUS, NZ, ZA
EUROPE
Shock absorber travel 132 mm (5.20 in) ← ----
Spring free length 260 mm
(10.24 in)
275 mm
(10.83 in)
----
Fitting length 248 mm
(9.76 in)
260 mm
(10.24 in)
----
<Min.~Max.> 240.5~ 258.5 mm
(9.47 ~ 10.18 in)
255.5~ 273.5 mm
(10.06 ~ 10.77 in)
----
Spring rate, STD K = 46.0 N/mm
(4.70 kg/mm,
263.2 lb/in)
K = Approx.
48.0 N/mm
(4.90 kg/mm,
274.4 lb/in)
----
Optional spring Yes ← ----
Enclosed gas pressure 1,000 kPa
(10 kg/cm
2
,
142 psi)
← ----
Swingarm:
Swingarm free play limit
End ---- 1.0 mm (0.04 in)
