Yamaha WR250F 2003 [210/304] Front wheel and rear wheel

5 - 6

CHAS

FRONT WHEEL AND REAR WHEEL

5. Install:

● Wheel axle 1

NOTE:

Apply the lithium soap base grease on the

wheel axle.

6. Install:

● Nut (wheel axle) 1

105 Nm (10.5 m · kg, 75 ft · lb)

7. Tighten:

● Bolt (axle holder) 1

NOTE:

Before tightening the bolt, fit the wheel axle to

the axle holder by stroking the front fork sev-

eral times with the front brake applied.

8. Install:

● Brake hose 1

To brake hose holder 2.

NOTE:

Before tightening the bolt (brake hose holder),

align the top a of the brake hose neck with the

brake hose holder bottom b. Then pass the

brake hose in front of the axle boss c and fit it

into the hose groove d so that the brake hose

does not contact the nut (wheel axle).

23 Nm (2.3 m · kg, 17 ft · lb)

10 Nm (1.0 m · kg, 7.2 ft · lb)
