2-20 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
034-701 No Dial Tone
034-701 Fax
Job Failure
No Dial Tone 2-88
034-702
to
034-711
Communication Fail
034-7xx Fax
Job Failure
Communication Errors 2-89
034-712
to
034-727
Communication Fail
034-7xx Fax
Job Failure
Fax transmission errors 2-90
034-750
to
034-768
Communication Fail
034-7xx Fax
Job Failure
RX Communication Errors 2-91
041-340 041-340
Code:xxxxxxxx
Restart Printer
MCU NVRAM Error 2-92
061-370 061-370 Printer
Code:xxxxxxxx
Restart Printer
LPH Failure 2-93
062-321 062-321 System
Restart Printer
Carriage Motor Error 2-94
062-790 Confirm
062-790
Deleted by Limit
Copy Limit 2-95
075-100 Paper Jam
075-100 Printer
Jam at Feed
Misfeed Jam 2-96
075-921 075-921 Printer
Insert Output to Tray
Waiting for OK to be pressed
after setting side 2 for manual
duplex print.
2-97
077-100 Paper Jam
077-100 Printer
Jam at Feed
Reg On Early Jam 2-98
077-104 Paper Jam
077-104 Printer
Jam at Exit
Reg Off Jam 2-99
077-106 Paper Jam
077-106 Printer
Jam at Exit
Exit On Jam 2-100
077-108 Paper Jam
077-108 Printer
Jam at Exit
Exit Off Early Jam 2-101
077-109 Paper Jam
077-109 Printer
Jam at Exit
Exit Off Jam 2-101
077-304 Close Rear Cover
077-304 Printer
Rear Cover
is Open
Rear Door Open 2-102
WorkCentre 3045 Error Message Summary
Code Error Message LCD Error Description Go to
