Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-21
Error Troubleshooting
077-900 Paper Jam Remain at Exit
077-900 Printer
Open Rear Cover
Remove Paper
Exit Jam 2-104
077-901 Paper Jam Remain at Reg
077-901 Printer
Open Rear Cover
Remove Paper
Remain Registration Jam 2-104
091-402 091-402 Printer
Contact Support
If Message Returns
Xero Life Warning 2-105
092-651 092-651
Code:xxxxxxxx
Restart Printer
ADC Sensor Error 2-106
092-661 092-661
Code:xxxxxxxx
Restart Printer
ENV Sensor Error 2-107
093-426 Ready to Print
093-42X Printer Cartridge
is Close to Life
Toner Cartridge Near end of Life 2-108
093-926 CRUM ID
093-926
Reseat Cartridge
Toner Cartridge CRUM ID Error 2-110
093-933 Replace Cart.
093-93X Printer
Replace Cartridge
Toner Cartridge Empty 2-108
093-974 Insert Print Cart
093-974 Printer
Insert
Toner Cartridge
Insert Print Cartridge 2-110
116-210 116-210 System
Restart Printer
Contact Support
If Message Returns
System USB Port Error 2-111
116-314 116-314 System
Restart Printer
Contact Support
If Message Returns
MAC Address Error 2-112
116-325 116-325 System
Restart Printer
Contact Support
If Message Return
Checksum Error 2-112
116-326 116-326 System
Restart Printer
Contact Support
If Message Returns
NVRAM Error 2-59
116-335 116-335 System
Restart Printer
Contact Support
If Message Returns
Checksum Error (Network) 2-112
WorkCentre 3045 Error Message Summary
Code Error Message LCD Error Description Go to
