83
11
DIGITAL MODE OPERATION
z Push [
SET
B (D-OFF)] to enter message set
mode.
• Push [
YY
] or [
ZZ
] to select “MESSAG” if necessary.
x Push [
SET
B(D-OFF)] or [
ENT
C (T-OFF)] several
times to select “TXM-C.”
c Push [BAND] then push [
YY
] or [
ZZ
] to select the
message channel.
• One of either “C1” to ”C6” blinks.
v Push [BAND] for 1 sec. to enter message pro-
gramming mode.
• The 1st digit blinks and channel indicator stops blink-
ing.
b Push [
YY
] or [
ZZ
] to select the desired character.
• Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)] to move the
cursor right or left, respectively.
n Push [
SET
B(D-OFF)] to select the 2nd digit, then
push [
YY
] or [
ZZ
] to select the desired character.
• 2nd digit blinks and 1st digit stops blinking.
• Repeat this step for programming.
m Push [BAND] for 1 sec. to save the message.
, Repeat steps x to m to set another message
channels.
. Push [
CLR
A(MW)] to exit the message set mode.
• Available characters
(3)
(D)
(N)
(X)
(+)
(4)
(E)
(O)
(Y)
(–)
(”)
(5)
(F)
(P)
(Z)
(✱)
(6)
(G)
(Q)
(/)
(7)
(H)
(R)
(,)
(8)
(I)
(S)
(space)
(9)
(T)
(0)
(A)
(U)
(1)
(B)
(V)
(2)
(C)
(J) (K)
(L)
(M)
(W)
(.)
(
))((
)(’)(&)(
%
)($)(#)(!)
(<)(:) (;)
(=)
(>)
(?)
(@)
([)
(\)
(])
(^)
SET
B
ID-800H_1.qxd 2007.06.14 3:09 PM Page 83
