Icom ID-800H [143/144] Mode arrangement
![Icom ID-800H [143/144] Mode arrangement](/views2/1074464/page143/bg8f.png)
126
15
MODE ARRANGEMENT
15
SET MODE
• Weather alert* (p. 98)
• Display dimmer (p. 95) • Display color (p. 95)
• Repeater tone
frequency (p. 95)
• Tone squelch
frequency (p. 95)
• DTCS code (p. 96)
• DTCS polarity (p. 96)
• Offset frequency (p. 96)
• Tuning step (p. 96)
• Scan resume timer
(p. 97)
• Channel skip setting
‡
(p. 97)
• Bank link function
‡
• Program skip
†
(p. 98)
• Bank setting
‡
(p. 97)
• Memory name
‡
(p. 97)
*Available for USA version only.
†
Appears when accessing set mode from VFO mode only.
‡
Appears when accessing set mode from memory mode only.
: Push (front panel); or (microphone)
: Push (front panel); or (microphone)
VFO mode
Memory mode
(p. 98)
Set mode items
for DV mode
pgs. 99–103
ID-800H_1.qxd 2007.06.14 3:09 PM Page 126
