68
11
DIGITAL MODE OPERATION
11
■ About D-STAR system
In the D-STAR system, repeater linking via a 10 GHz band
backbone and internet network (gateway connection) capa-
bilities are available. This system provides you to with much
wider coverage range during digital voice mode operation.
• D-STAR system outline
About time-out timer function
The ID-800H has a time-out timer function for digital re-
peater operation. The timer limits a continuous transmis-
sion for approx. 10 min. Warning beeps will sound before
30 sec. (approx.) and just before the timer functioning.
ID-800H_1.qxd 2007.06.14 3:09 PM Page 68
