Icom ID-800H [41/144] Repeater operation
![Icom ID-800H [41/144] Repeater operation](/views2/1074464/page41/bg29.png)
24
4
REPEATER OPERATION
4
z Set the frequency band, mode/channel you wish
to set the subaudible tones, such as VFO mode
or memory/call channel.
• The subaudible tone frequency is independently pro-
grammed into each mode or channel.
x Push [
SET
B(D-OFF)] to enter set mode.
• Push [
YY
] or [
ZZ
] to select “SET,” if necessary.
c
Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)] several
times until “T”
and “rT” appears; or until “T SQL”
and “CT” appears for tone squelch or pocket
beep use.
•
When “d” is displayed in place of the 100 MHz digit,
cancel the DTMF memory encoder in advance. (p. 53)
v Push [
YY
] or [
ZZ
] to select and set the desired
subaudible tone frequency.
• Push and hold [
YY
]/[
ZZ
] to change the above tones
continuously.
b Push [
CLR
A(MW)] to exit set mode.
Push
SET
B
ID-800H_1.qxd 2007.06.14 3:09 PM Page 24
