Icom ID-800H [61/144] Scan operation
![Icom ID-800H [61/144] Scan operation](/views2/1074464/page61/bg3d.png)
44
7
SCAN OPERATION
7
z Push [VFO/LOCK] to select VFO mode for
full/programmed scan; push [MR/CALL] to se-
lect memory mode for memory scan.
• Push [FUNC] then [
MONI
1(BANK)] to select a bank
for bank scan.
x Push [
SQL
YY
D(MUTE)] or [
SQL
ZZ
#(16KEY-L)] to
set the squelch to the point where noise is just
muted.
c Push [
SCAN
2(T-SCAN)] to start the scan.
• Push and hold [
YY
] or [
ZZ
] for 1 sec. also starts the
scan.
v Push [
SET
B(D-OFF)] to switch full and pro-
grammed scan (P1, P2, P3, P4 and P5), if VFO
is selected in step z.
b To stop the scan push [
SCAN
2(T-SCAN)] or
[
CLR
A(MW)].
NOTE: When AM, FM or DV mode frequencies are pro-
grammed into memory channels disorderly, memory scan
takes a lot of time (very slow). Because changing modes
takes a time. In this case, assign the AM, FM and DV
mode frequencies into the separate bank respectively. And
using the bank scan is helpful.
SCAN
2
SET
B
ID-800H_1.qxd 2007.06.14 3:09 PM Page 44
