75
11
DIGITAL MODE OPERATION
DD
Repeater operation into another zone
qSet the desired repeater’s frequency, offset and shift direc-
tion in VFO mode.
(p. 21)
• Select “DV” mode in advance.
wSet your own call sign. (p. 65)
• See p. 61 for your own call sign programming.
eSet the desired station call sign. (pgs. 66, 67)
• When making a CQ call
Set the desired repeater’s
(in a different zone) call sign, for
the area you want to make a CQ call, into “UrCALL.”
-
“/,” stands for “CQCQCQ,” is added at the 1st digit automatically.
• See p. 63 for station call sign programming.
rSet the repeater’s call sign as follows;
a Push [SET•LOCK] to enter call sign set mode.
• Rotate [DIAL] to select “CALL” if necessary.
s Push [SET•LOCK] or [S.MW•MW] several times to se-
lect “RPT1 C.”
d Rotate [DIAL] to select the nearest repeater’s call sign.
f Push [SET•LOCK] for 1 sec. to set the call sign for
“RPT1 C.”
g Push [SET•LOCK] to select “RPT2 C.”
h Rotate [DIAL] to select the gateway repeater’s
(in the
same zone) call sign.
• The call sign should have “G” setting as the 8th digit.
• Push [SET•LOCK] or [S.MW•MW] to display last 6-digit or
first 6-digit of the call sign, respectively.
j Push [SET•LOCK] for 1 sec. to set the call sign for
“RPT2 C.”
k Push one of [TONE•T-SCAN•BK], [LOW•DUP] or
[MONI•DTMF•EMR] to exit call sign set mode.
tPush [PTT] to transmit; release to receive.
ID-800H_1.qxd 2007.06.14 3:09 PM Page 75
