Icom ID-800H [90/144] D repeater operation in the same zone
![Icom ID-800H [90/144] D repeater operation in the same zone](/views2/1074464/page90/bg5a.png)
73
11
DIGITAL MODE OPERATION
DD
Repeater operation in the same zone
qSet the desired repeater’s frequency, offset and shift direc-
tion in VFO mode.
(p. 21)
• Select “DV” mode in advance. (p. 15)
wSet your own call sign. (p. 65)
• See p. 61 for your own call sign programming.
e Set the desired station call sign. (pgs. 66, 67)
• See p. 63 for station call sign programming.
r Set the repeater’s call sign as follows;
a Push [SET•LOCK] to enter call sign set mode.
• Rotate [DIAL] to select “CALL” if necessary.
s Push [SET•LOCK] or [S.MW•MW] several times to se-
lect “RPT1 C.”
d Rotate [DIAL] to select the nearest repeater’s call sign.
f Push [SET•LOCK] for 1 sec. to set the call sign for
“RPT1 C.”
g Push [SET•LOCK] to select “RPT2 C.”
h Rotate [DIAL] to select the desired repeater’s
(in the
same zone) call sign.
• Select “r - - (NOTUSE)” when not operating RPT2.
j Push [SET•LOCK] for 1 sec. to set the call sign for
“RPT2 C.”
k Push one of [TONE•T-SCAN•BK], [LOW•DUP] or
[MONI•DTMF•EMR] to exit call sign set mode.
t Push [PTT] to transmit; release to receive.
z Set the desired repeater’s frequency, offset and
shift direction in VFO mode.
(p. 22)
• Select “DV” mode in advance. (p. 15)
x Set your own call sign. (p. 65)
• See p. 62 for your own call sign programming.
c Set the desired station call sign. (pgs. 66, 67)
• See p. 64 for station call sign programming.
v Set the repeater’s call sign as follows;
a
Push [
SET
B(D-OFF)] to enter call sign set mode.
• Push [
YY
] or [
ZZ
] to select “CALL” if “SET” or “MES-
SAG” is displayed.
s Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)] sev-
eral times to select “RPT1 C.”
d Push [
YY
] or [
ZZ
] to select the nearest re-
peater’s call sign.
f Push [
SET
B(D-OFF)] for 1 sec. to set the call
sign for “RPT1 C.”
g Push [
SET
B(D-OFF)] to select “RPT2 C,” then
push [BAND].
h Push [
YY
] or [
ZZ
] to select the desired re-
peater’s
(in the same zone) call sign.
• Select “r - - (NOTUSE)” when not operating RPT2.
j Push [
SET
B(D-OFF)] for 1 sec. to set the call
sign for “RPT2 C.”
k Push [
CLR
A(MW)] to exit call sign set mode.
b Push [PTT] to transmit; release to receive.
SET
B
ID-800H_1.qxd 2007.06.14 3:09 PM Page 73
