DIGITAL MODE OPERATION
11
z Push [
SET
B(D-OFF)] to enter call sign set mode.
• Push [
YY
] or [
ZZ
] to select “CALLS,” if necessary.
x Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)] several
times to select “UrCALL,” then push [BAND].
c Push [
YY
] or [
ZZ
] to select the desired call sign
channel.
v Push [BAND] for 1 sec. to enter call sign pro-
gramming mode.
• The 1st digit blinks.
b Push [
YY
] or [
ZZ
] to select the desired character
or code.
• Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)] to move the
cursor right or left respectively.
n Push [
SET
B(D-OFF)] to select 2nd digit, then
push [
YY
] or [
ZZ
] to select the desired character or
code.
• The 2nd digit blinks (1st digit stops blinking).
• Repeat this step for programming other station call
sign.
m Push [BAND] for 1 sec. to save the call sign.
, Push [
YY
] or [
ZZ
] to select an another channel
from “U01” to “U99.”
. Repeat c to m to program another station call
sign channels.
⁄0 Push [
CLR
A(MW)] to exit call sign set mode.
NOTE: During the call sign programming mode (v to n),
push [VFO/LOCK] to clear the entered call sign
(the cursor
returns to the 1st digit position), push [VFO/LOCK] again to
select “CQCQCQ,” “/” and the previously saved call sign.
IMPORTANT! The “!” indicator appears when the se-
lected call sign channel is used for some memory or call
channels. The desired call sign can be over-written even
the “!” indicator is displayed, however, “MR ✱” is dis-
played while [BAND•MOD]
(or [BAND]) is pushed and the
previously memorized setting in memory or call channels
are also changed at the same time.
SET
B
