PANEL DESCRIPTION
1
tOUTPUT POWER INDICATORS (p. 19)
➥ “LOW” appears when low output power is selected.
➥ “MID” appears when middle output power is selected.
➥ No indicator appears when high output power is se-
lected.
yMODE INDICATORS
(p. 15)
➥ “AM” appears while in the AM mode operation.
➥ “NAR” appears while in the FM/AM narrow mode oper-
ation.
➥ “DV” appears while in the digital mode operation.
➥ No indication appears while in the FM mode operation.
• Blinking all indication indicates the FM mode selection while
setting.
uDIGITAL MESSAGE INDICATOR (p. 83)
Blinks when a digital message is received.
• The indication disappears when any key is pushed.
iSQUELCH ATTENUATOR INDICATOR (p. 17)
Appears when the squelch attenuator function is activated.
• The attenuator can be switched OFF in initial set mode. (p. 104)
oMEMORY INDICATOR (pgs. 11, 28)
Appears when memory mode is selected.
!0SKIP INDICATORS
(p. 47)
➥ “~” appears when the displayed memory channel is
specified as a skip channel.
➥ “P ~” appears when the displayed frequency is spec-
ified as a program skip frequency.
!1MEMORY CHANNEL NUMBER INDICATORS
➥ Shows the selected memory channel number.
(p. 28)
➥ Shows the selected bank initial. (p. 37)
➥ “C” appears when the call channel is selected. (p. 40)
➥ “L” appears when the lock function is activated. (p. 14)
!2PRIORITY INDICATOR (p. 50)
Appears while priority watch is activated; blinks while the
watch is paused.
!3WEATHER ALERT INDICATOR
(p. 111)
Appears when the weather alert function is activated.
• The either alert function is available with the USA version only.
!4AUDIO MUTE INDICATOR (p. 18)
Appears when the audio mute function is activated.
• The mute can only be switched ON and OFF from the HM-133
only.
!5AUTO POWER-OFF INDICATOR (p. 107)
Appears while the auto power OFF function is in use.
