OTHER FUNCTIONS
Set mode items
for DV mode
pgs. 99–103
• Weather alert*
• Display dimmer • Display color
• Repeater tone
frequency
• Tone squelch
frequency
• DTCS code
• DTCS polarity
• Offset frequency
• Tuning step
• Scan resume timer
• Channel skip setting
‡
• Bank link function
‡
• Program skip
†
• Bank setting
‡
• Memory name
‡
*Available for USA version only.
†
Appears when accessing set mode from VFO mode only.
‡
Appears when accessing set mode from memory mode only.
: Push (front panel); or (microphone)
: Push (front panel); or (microphone)
VFO mode
Memory mode
DD
Set mode items (VFO/Memory mode)
