Icom ID-800H [141/144] Mode arrangement
![Icom ID-800H [141/144] Mode arrangement](/views2/1074464/page141/bg8d.png)
124
15
MODE ARRANGEMENT
15
• Key-touch beep (p. 106) • Time-out timer (p. 106)
• Auto repeater* (p. 106)
(USA version only) • Auto power off (p. 107) • Cooling fan (p. 107)
• Squelch delay (p. 108)
• Active band (p. 109)• DTMF speed (p. 110)
• Data speed for DV mode (p. 110)
• Standby beep (p. 110)
• Busy lockout* (p. 110)
• Narrow transmission (p. 109)
INITIAL SET MODE
• Data speed for
FM mode (p. 108)
• Microphone
sensitivity (p. 108)
• Squelch attenuator
(p. 108)
*Available in the USA version only.
: Push (front panel); or (microphone)
: Push (front panel); or (microphone)
ID-800H_1.qxd 2007.06.14 3:09 PM Page 124
