Thank you for purchasing this Icom product. The ID-800H
VHF
/
UHF DIGITAL TRANSCEIVER
is designed and built with Icom’s
state of the art technology and craftsmanship. With proper care,
this product should provide you with years of trouble-free oper-
ation.
We want to take a couple of moments of your time to thank
you for making your ID-800H your radio of choice, and hope
you agree with Icom’s philosophy of “technology first.” Many
hours of research and development went into the design of
your ID-800H.
DD
FEATURES
❍ DV mode (Digital voice + low-speed data
communication) available
– GPS receiver connection
– Text message and call sign exchange
❍ Switchable VHF and UHF transceiver
❍ 55 W*—high transmit output power
*VHF band; 50 W for UHF band
❍ Detachable controller for flexible installation
❍ Large tuning dial and band switch button
❍ Selectable backlit color from amber, green
and yellow
❍ Total 512 memory channels with bank link
scan
❍ Remote control microphone standard
