OTHER FUNCTIONS
■ Microphone keys
The supplied HM-133’s (optional for some versions) [F-1] and
[F-2] keys memorize the transceiver conditions.
The [UP]/[DN] keys of the standard or an optional micro-
phone (other than the HM-133) can be assigned functions like
the function keys on the transceiver’s front panel.
DD
[UP]/[DN] keys on a microphones
(other than HM-133)
The following functions are assigned to [UP]/[DN] keys on the
other microphones (HM-118N, etc.) when first applying power.
• Default setting
[UP] : channel up; push and hold to start scan, push again
to stop scan.
[DN] : channel down; push and hold to start scan, push
again to stop scan.
➥ Assigning a function
q Turn the power OFF.
w While pushing the desired switch on the transceiver and
one of either [UP]/[DN] keys on the microphone, turn the
power ON.
• The function is programmed into the key.
➥ Clearing an assignment
q Turn the power OFF.
w While pushing the desired [UP] or [DN] key on the micro-
phone, turn the power ON.
DD
[F-1]/[F-2] keys on HM-133
The following conditions can be memorized into [F-1] and
[F-2] keys, independently.
• Operating frequency
• Repeater setting
(offset direction and frequency, tone ON/OFF
and frequency)
• Tone/DTCS squelch (ON/OFF, frequency/code and polarity)
• Transmit output power selection
• Tuning step
• Operating mode selection
➥ Programming the band condition
Push and hold for [F-1]/[F-2] for 1 sec.
• 3 beeps sound.
➥ Recalling the band condition
Push [F-1]/[F-2] momentarily.
And, the set call signs
(“UrCALL,” “RPT1 C” and “RPT2 C”), set
mode and initial set mode setting conditions can additionally
be memorized with [FUNC] and [F-1]/[F-2] keys operation,
independently.
➥ Programming the band condition
Push [FUNC] then push and hold [F-1]/[F-2]
for 1 sec.
➥ Recalling the band condition
Push [FUNC] then push [F-1]/[F-2].
[F-1]/[F-2]
[F-1]/[F-2]
AT
POWER ON
