SCAN OPERATION
7
D Programming scan edges via microphone
z Set the desired frequency in VFO mode.
➥ Push [VFO/LOCK] to select VFO mode.
➥ Set the frequency via the keypad or [
YY
]/[
ZZ
].
x Push [FUNC] then [
CLR
A(MW)] momentarily.
c Push [
YY
] or [
ZZ
] to select scan edge channels,
1A, 2A, 3A, 4A or 5A.
v Push [FUNC], and then push and hold
[
CLR
A(MW)] for 1 sec. to program.
• 3 beeps sound and VFO is automatically selected.
• Memory channel number advances to the next scan
edge channel, 1B, 2B, 3B, 4B or 5B when continuing
to push [
CLR
A(MW)] after programming.
b To program a frequency for the other scan edge channels,
repeat steps z to v.
MW
[EXAMPLE]: Programming 145.800 MHz into scan edge 1B.
Push
Push
Push then momentarily
Push
Push then for 1 sec. and continue to push
➠
Beep
“
Beep
Beep
Beep
“
“
“
“
“
