GENERAL INFORMATION 1-4
SPECIFICATIONS
Items LV1000-A1
Dimensions:
Overall length 2 295 mm (90.4 in.)
Overall width 910 mm (35.8 in.)
Overall height 1 395 mm (54.9 in.)
Wheelbase 1 535 mm (60.4 in.)
Road clearance 165 mm (6.5 in.)
Seat height 840 mm (33.1 in.)
Dry mass 208 kg (458 lbs)
Fuel tank capacity 22 L (5.81 US gal)
Performance:
Minimum turning radius 2.7 m (106.3 ft.)
Engine:
Type 4-stroke, DOHC, V2-cylinder
Cooling system Liquid-cooled
Bore and stroke
98.0 u 66.0 mm (3.858 u 2.598 in.)
Displacement 996 mL (60.8 cu in.)
Compression ratio 11.3
Carburetion system FI (Fuel Injection)
Starting system Electric starter
Ignition system Electronic ignition (transistorized)
Ignition timing
4q BTDC @ 1 200 r/min (rpm)
Spark plugs NGK CR8EK or ND U24ETR
Lubrication system Forced lubrication (wet sump with cooler)
Engine oil:
Type API SF or SG
Viscosity SAE10W-40
Capacity 3.3 L (3.5 US qt)
Drive Train:
Primary reduction system:
Type Gear
Reduction ratio 1.838 (57/31)
Clutch type Wet multi disc
Transmission:
Type 6-speed, constant mesh, return shift
Gear ratios: 1st 3.000 (36/12)
2nd 1.933 (29/15)
3rd 1.500 (27/18)
4th 1.227 (27/22)
5th 1.086 (25/23)
6th 0.913 (21/23)
