FI SYSTEM 4-59
THROTTLE BODY AND STV ACTUATOR
CONSTRUCTION
5 N
.
m
(0.5 kgf-m, 3.7 lb-ft)
3 N
.
m
0.3 kgf-m,
2.0 lb-ft
( )
2 N
.
m (0.2 kgf-m, 1.5 lb-ft)
5 N
.
m
(0.5 kgf-m, 3.7 lb-ft)
3.5 N
.
m
(0.35 kgf-m, 2.5 lb-ft)
2 N
.
m
0.2 kgf-m
1.5 lb-ft
()
5 N
.
m
(0.5 kgf-m, 3.7 lb-ft)
TP sensor
STP sensor
STV actuator
STV actuator
lead wire connector
Fuel delivery pipe
O-ring
Dust seal
Injector
Cushion seal
3.5 N
.
m (0.35 kgf-m, 2.5 lb-ft)
VIEW OF TOP
Intake pipe side
Air cleaner side15˚ – 25˚
15˚ – 25˚
#1
#1
#2
#2
Forward
