Throughout this manual are symbols indicating instructions and other information necessary for servicing.
The meaning of each symbol is included in the table below. Where applicable, comparable Kawasaki
products and their part numbers have been included.
SYMBOL SUZUKI DEFINITION KAWASAKI DEFINITION
Torque control required.
Data beside it indicates specified torque.
m
Indicates service data.
m
Apply oil. Use engine oil unless otherwise
specified.
m
Apply molybdenum oil solution.
(mixture of engine oil and SUZUKI MOLY PASTE
in a ratio of 1 : 1)
Apply molybdenum disulfide oil.
(a mixture of engine oil and
molybdenum disulfide grease with
a weight ratio of 1:1)
Apply SUZUKI SUPER GREASE “A”.
99000-25030 (For USA)
99000-25010 (For the other countries)
Apply grease.
Apply SUZUKI SILICONE GRESE.
99000-25100
Apply Silicone grease.
Apply SUZUKI MOLY PASTE.
99000-25140
Apply molybdenum disulfide
grease.
Apply SUZUKI BOND “1207B”.
99104-31140 (For USA)
99000-31140 (For the other countries)
Apply THREE BOND “TB1207B”.
Apply SUZUKI BOND “1215”.
99000-31110 (Except USA)
Apply THREE BOND “TB1215”.
Apply THREAD LOCK SUPER “1303”.
99000-32030
Apply a non-permanent locking
agent.
Apply THREAD LOCK SUPER “1322”.
99000-32110 (Except USA)
Apply a non-permanent locking
agent.
Apply THREAD LOCK “1342”.
99000-32050
Apply a non-permanent locking
agent.
