SYMBOL SUZUKI DEFINITION KAWASAKI DEFINITION
Apply or use brake fluid,
m
Measure in voltage range.
m
Measure in resistance range.
m
Measure in current range.
m
Measure in diode test range. Use a suitable commercially
available digital multi meter for a
diode tester and measure in diode
test range.
Measure in continuity test range.
m
Use special tool. Refer to the special tools in
Servicing Information chapter.
Use engine coolant.
99000-99032-11X (Except USA)
m
Use fork oil.
99000-99001-SS8
Front Fork Oil Viscosity
SAE 10W-20
Use rear shock absorber oil.
99000-99001-S25
m
