10-10 DL1000K3 (’03-MODEL)
ELECTRICAL Unit: mm (in)
ITEM SPECIFICATION NOTE
Ignition timing 4° B.T.D.C. at 1 200 r/min
Firing order 1·2
Spark plug
Type
NGK: CR8EK
Denso: U24ETR
Gap
0.6 – 0.7
(0.024 – 0.028)
Spark performance Over 8 (0.3) at 1 atm.
Crankshaft position sensor
resistance
130 – 240 Ω Bl – G
Ignition coil resistance Primary 2 – 5 Ω
tap –
tap
Secondary 24 – 37 kΩ
tap – Plug cap
Crankshaft position sensor peak
voltage
More than 3.7 V When cranking
Ignition coil primary peak volt-
age
More than 150 V When cranking
Generator coil resistance 0.2 – 0.5 Ω Y – Y
Generator Max. output Approx. 400 W at 5 000 r/min
Generator no-load voltage
(When engine is cold)
More than 75 V (AC) at 5 000 r/min
Regulated voltage 14.0 – 15.5 V at 5 000 r/min
Starter relay resistance 3 – 6 Ω
Battery Type
designation
FTX14-BS
Capacity 12 V 43.2 kC (12 Ah)/10 HR
Fuse size
Headlight
HI 15 A
LO 15 A
Turn signal 15 A
Ignition 15 A
Fan motor 15 A
Meter 10 A
Main 30 A
