11-14 DL1000K4 (’04-MODEL)
ENGINE INSTALLATION
Remount the engine in the reverse order of engine removal.
Pay attention to the following points:
NOTE:
* The engine mounting nuts are self-locking.
* Once the nut has been removed, it is no longer of any use. Be sure to use new nuts, and then tighten them
to the specified torque.
ITEM N·m kgf-m lb-ft
55 5.5 40.0
23 2.3 16.5
12 1.2 8.5
45 4.5 32.5
75 7.5 54.0
FWD
RH
LH
RH
LH
