![Kawasaki KLV1000 (2004) [453/529] Brake pedal footrest set up](/img/pdf.png)
Kawasaki KLV1000 (2004) [453/529] Brake pedal footrest set up
![Kawasaki KLV1000 (2004) [453/529] Brake pedal footrest set up](/views2/1121213/page453/bg1c5.png)
8-30 SERVICING INFORMATION
SIDE-STAND SET-UP
BRAKE PEDAL/FOOTREST SET-UP
50 N
.
m
(5.0 kgf-m, 36.0 lb-ft)
40 N
.
m
(4.0 kgf-m, 29.0 lb-ft)
()
100 N
.
m
10.0 kgf-m
72.5 lb-ft
Brake light switch
Pin
Footrest
Bracket
E-ring
Inside
Inside
Inside
OutsideOutside
