6-2 CHASSIS
EXTERIOR PARTS
CONSTRUCTION
ITEM N·m kgf-m lb-ft
" 35 3.5 25.5
"
Screen
Cowling brace
Fuel tank top cover
Combination meter panel
Cowling body
Right cowling
Left cowling
Left side cowling
Right side cowling
Inner cowling
" Engine under cover
" Cowling brace mounting bolt
