PERIODIC MAINTENANCE 2-15

MAJOR ADJUSTMENT

• Remove the fuel tank. (4-52)

• Remove the air cleanet box. (4-60)

• Loosen the locknut

 of the throttle returning cable.

• Turn the returning cable adjuster

 to obtain proper cable

play.

• Loosen the locknut

 of the throttle pulling cable.

• Turn the pulling cable adjuster

 in or out until the throttle

cable play

" should be 2.0 – 4.0 mm (0.08 – 0.16 in) at the

throttle grip.

• Tighten the locknut

 securely while holding the adjuster

.

Throttle cable play

": 2.0 – 4.0 mm (0.08 – 0.16 in)

• While holding the throttle grip at the fully closed position,

slowly turn the returning cable adjuster

 to obtain a slack of

1.0 mm (0.04 in).

• Tighten the locknut

 securely.

THROTTLE VALVE SYNCHRONIZATION

(4-72)

PAIR (AIR SUPPLY) SYSTEM

(9-6)

After the adjustment is completed, cheack that han-

dlebar movement does not raise the engine idle speed

and that the throttle grip returns smoothly and auto-

matically.

Inspect every 12 000 km (7 500 miles, 12 months).
