1-10 GENERAL INFORMATION
COUNTRY AND AREA CODES
The following codes stand for the applicable country(-ies) and area(-s).
CODE COUNTRY or AREA
E-02
E-03
E-19
E-24
E-28
E-33
U. K.
U. S. A. (Except for California)
EU
Australia
Canada
California (U. S. A.)
