Kawasaki KLV1000 (2004) [451/529] Pair air supply system hose routing
![Kawasaki KLV1000 (2004) [451/529] Pair air supply system hose routing](/views2/1121213/page451/bg1c3.png)
8-28 SERVICING INFORMATION
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING
For European markets
For USA/CANADA/AUSTRALIA
Matching mark
(White)
VIEW OF TOP SIDE
Matching mark
(White)
VIEW OF RIGHT SIDE
PAIR reed valve
PAIR valve
From air cleaner
10 N·m
(1.0 kgf-m, 7.3 lb-ft)
Matching mark
(Yellow)
Matching mark
(White)
Vacuum hose
Matching mark
(White)
To throttle body
VIEW OF TOP SIDE
VIEW OF RIGHT SIDE
From air cleaner
PAIR valve
PAIR reed valve
Matching mark
(Yellow)
10 N·m
( )
1.0 kgf-m
7.3 lb-ft
