CHASSIS 6-11
REASSEMBLY AND REMOUNTING
Reassemble and remount the front wheel in the reverse order of removal and disassembly. Pay attention to
the following points:
Left Right
23 N
.
m
(2.3 kgf-m, 16.5 lb-ft)
()
()
()
()
()
39 N
.
m
3.9 kgf-m
28.0 lb-ft
23 N
.
m
2.3 kgf-m
16.5 lb-ft
39 N
.
m
3.9 kgf-m
28.0 lb-ft
23 N
.
m
2.3 kgf-m
16.5 lb-ft
100 N
.
m
10.0 kgf-m
72.5 lb-ft
