FI SYSTEM 4-21
ECM
Intake air temperature sensor (IATS)
Intake air pressure sensor (IAPS)
Camshaft position sensor (CMPS)
Engine coolant temperature sensor (ECTS)
Gear position switch
Heated oxygen sensor (HO
2S)
PAIR solenoid valve
Fuel injector (FI)
