9-2 EMISSION CONTROL INFORMATION
EMISSION CONTROL SYSTEMS
FUEL INJECTION SYSTEM
DL1000 motorcycles are equipped with a fuel injection system for emission level control.
This fuel injection system is precision designed, manufactured and adjusted to comply with the applicable
emission limits.
Fuel pressure
regulator
Fuel pump
Fuel mesh filter
(For low pressure)
Fuel feed hose
Fuel injector
Fuel filter
(For high pressure)
BEFORE-PRESSURIZED
FUEL
RELIEVED FUEL
PRESSURIZED FUEL
